The Deviate Chain Guide
The Deviate Chain Guide is the result of over a year's R&D and testing in Scotland and the Alps by both our engineering team and ambassadors.
Eliminating dropped chains is at the core of any chain guide, but Deviate’s design also tackles key challenges including durability, reliability, drag and even noise
KEY FEATURES
Adjustability : Works with chain ring sizes from 30T to 36T
Durability : Grease port is fitted to protect the bearings (as seen on Deviate’s Highlander and Claymore frames)
Reliability : Designed with long rides & racing in mind. Reduce maintenance with built in grease ports, twin-lip wiper seals and pre-mounted bash guard
Efficiency : Jockey-wheel system improves guide efficiency by reducing the risk of the chain siezing
Noise-reduction : Soft rubber included to reduce noise
Drag-reduction : The grease ports not only provide longevity but also reduce drag on the ups
Protection : Comes complete with pre-mounted and adjustable bash guard
Compatibility : ISCG 05 lower only chain guide. Works with a range of suspension platforms (not just high pivot) and oval chain rings
Part Replacement : No need to replace the entire guide, the bash guard and jockey wheel can be easily replaced
Installation : Install without removing your crank
Specification
Chainline : 52mm (55mm with 3mm spacers and longer screws)
Material : Injection moulded nylon & CNC-machined Aluminum backplate
Capacity : 30-36T
Weight : 109g
Mount : ISCG 05 lower only
Whilst not tested outside of the Deviate bike range, it should be fully compatible with most other analogue mountain bike frame
